Designed for the players redefining what heavy looks like, the Fender® Limited Edition Fusion Series takes the most iconic silhouettes in guitar history and strips away everything that doesn't serve the riff. High-output humbuckers and noiseless single coils deliver the kind of tonal aggression that sits in a dense, down-tuned mix without disappearing. Built for the stage and the studio, the Fusion Series is Fender for the generation that plays loud and means it.
The Fusion Baritone Jaguar® goes lower, hits harder, and gives extended-range players a Fender platform that boldly keeps up. At 27" scale and tuned B to B, this Jaguar is purpose-built for drop tunings and the kind of low-end that sits at the foundation of a heavy mix. The classic Jaguar rhythm circuit control section gets a meaningful upgrade — it houses a “Spin-a-Split” wiring via Fender roller pots that progressively transform the humbuckers into single coils for a leaner, more cutting tone, while a TBX Tone circuit gives players more powerful tonal sculpting options. High-output humbuckers handle the heavy lifting across a 12" radius ebony fingerboard that keeps runs and bends effortless across the extended scale.
FEATURES
- 27" Baritone Scale Length, B-to-B Tuning
- Dual High-Output Humbuckers
- "Spin-a-Split" Circuit
- TBX Tone Circuit
- 12"-Radius Ebony Fingerboard
- Black Hardware
Specifications
Series: Player
Orientation: Right-Handed
Colour: Black
Country of Origin: Mexico
Body Shape: Jaguar®
Body Material: Alder
Body Finish: Gloss Polyester
Neck Material: Maple
Neck Finish: Satin Urethane
Neck Profile: Thin "C"
Neck Construction: 4-Bolt
Fingerboard Material: Ebony
Fingerboard Radius: 12" (305 mm)
Inlays: White Pearloid Dot (7 mm)
Side Dots: White
Scale Length: 27" (686 mm)
Number of Frets: 22
Fret Size: Jumbo
Nut Material: Synthetic Bone
Nut Width: 1.685" (42.8 mm)
Neck Thickness: .790" (1st Fret), .825" (12th Fret)
Bridge Pickup: Player II Modified Humbucker
Neck Pickup: Player II Modified Humbucker
Pickup Configuration: HH
Controls: Master Volume, Master TBX™ Tone Control
Switching: 3-Position Toggle Switch
Position 1: Bridge Pickup
Position 2: Bridge and Neck Pickups
Position 3: Neck Pickup
Special Electronics: Rhythm Circuit with Spin-a-Split Controls for Humbucker Coil Splitting
Bridge: Adjusto-Matic™
Tailpiece: Stop Tail
Tuners: Deluxe Staggered Cast/Sealed Locking
Hardware Finish: Nickel/Chrome
Pickguard: 3-Ply Black
Pickup Covers: Chrome
Control Knobs: Knurled Dome
Switch Tip: Black
Neck Plate: 4-Bolt
Factory Strings: Nickel Plated Steel (.013–.062)
