Gamechange Audio Plasma Pedal - Preowned

SKU 37115818
Original price $0
Original price $399.00 - Original price $399.00
Original price
Current price $399.00
$399.00 - $399.00
Current price $399.00
In Stock & Ready To Ship!
Or Rent From
$3.70 per weekReturn any time after minimum rental agreement

Have a Trade In?

We often accept trade ins towards new products!
Let us know what you would like to trade in via our Trade In Form.

Condition:

This effects pedal presents in excellent condition. There are some very minor scuff marks on the base of the unit and dust under the knobs. It has been tested for functionality. it comes as is with no additional accessories or box.

This effects pedal presents in excellent condition. There are some very minor scuff marks on the base of the unit and dust under the knobs. It has been tested for functionality. it comes as is with no additional accessories or box.

The PLASMA Pedal creates heavy distortion by amplifying an audio signal up to 3500 Volts and transforming it into electrical discharges. You are literally playing a bolt of electricity.

Rather than relying on traditional LED, transistor or vacuum-tube circuits to produce overdrive, the PLASMA Pedal fundamentally redefines the way that signal clipping can be achieved.

Inspired by Nikola Tesla's electrical resonant transformer circuit design (the Tesla Coil), it is the first effects unit to introduce a new method for signal clipping by converting the input signal into pure electrical discharges.

The blue light visible on the pedal's front panel is the actual electrical arc created by the audio input as it travels between two electrodes on either end of a specially designed xenon-filled gas discharge tube.

SPECIFICATIONS

Input type 1/4” Unbalanced TS
Input impedance 1MΩ
Max Input Level 7Vpp (+10dBu)
Output Type 1/4” Unbalanced TS
Output Impedance 100Ω
Max Output Level 7Vpp (+10dBu)
Power Connector Center negative 2.1 x 5.5 mm barrel plug (the standard 9V)
Frequency Response 20Hz to 22kHz
EQ LOW FRQ Boost/Cut ± 9dB, 600Hz corner Freq.
EQ HI FREQ Boost/Cut ± 10dB, 1.5kHz corner freq.
Indicator Check indicator white LED
Connectors IN, OUT, DC input
Power Requirements 300mA, 9VDC
Peak Power Consumption 2.7 W
Mean Power Consumption 1 W
Power Consumption during Stand-by 0.025 W
Dimensions 148 mm * 96 mm * 70 mm
